E Series Voltage Stabilize SER-3000
Quick Details
Place Of Origin: Guangdong, China (Mainland)
Brand Name: YINGHUA
Model Number: SER-3000
Usage: SVC
Phase: Single Phase
Current Type: AC
Type: Relay Type
Color: White
Display: LED graphic
Packaging & Delivery
| Packaging Details: | 1 piece with 1 individual box |
| Delivery Detail: | Within 7- 30 days after receiving the deposit |
Specifications
Patent technology AC voltage Stabilizers
Input: 140Vac- 260Vac
Output: 220vac, 50hz / 60hz
LED moudle display shows full status
Applications:
Computer,test equipments, lighting equipment, duplicators, stereo sound equipment, auto process control equipment, TV, office appliances, etc
Description:
SER Series AVR is integrated the self develop patent control mode, achieved the authentic zero crossing technology, which makes the relays switching on / offat the zero point, it reduces the shock to the relays and to the loads at the switching point, so that you can gain more smooth output and more durable relays. High performance and high speed MCU guarantees faster responding timeand its independent SMT processing MCU controlling board further guarantees thebest reliability.
| Model | SER-1000 | SER-1500 | SER-2000 | SER-3000 | SER-5000 | |
| Rated Capacity | 1000VA | 1500VA | 2000VA | 3000VA | 5000VA | |
| Phase | Single | |||||
| Transformer | C.R.G.O. toroidal transformer | |||||
| Indicator | LED graphic | |||||
| Display Status | working and loading | |||||
| Input | Voltage | 140~ 260 Vac | ||||
| Frequency | 50 / 60 Hz | |||||
| Output | Voltage | 110 / 120 / 220 / 230 / 240 Vac optional | ||||
| Precision | ±8% | |||||
| Protection | Overload | Yes | ||||
| High temperature | Yes | |||||
| High/low voltage | Yes | |||||
| Short circuit | Yes | |||||
| Delay Function | delay / un delay (180 / 6 seconds selectable) | |||||
| Efficiency | 98% | |||||
| Cooling system | Smart cooling for 3000Va and above | |||||
| Environmental | Operating temperature | 0 - 40 °C | ||||
| Relative humidity | 10%~102% RH, non condensing | |||||
| Storage temperature | -15 - 45 °C | |||||
| Appearance | AVR size (mm) | 230x145x180 | 355x220x250 | |||
| AVR N.W. (kg) | 3.00 | 3.40 | 3.70 | 6.80 | 7.80 | |
| Inner box size (mm) | 293x190x225 | 395x272x305 | ||||
| Qty/Ctn | 4 | 1 | ||||
| Carton size (mm) | 785x305x240 | 395x272x305 | ||||
| Carton G.W. (kg) | 13.80 | 15.60 | 16.60 | 7.60 | 8.60 | |
