    EPSI Series Pure sine wave inverter
    Automatic voltage Regulator (AVR) is designed to automatically maintain voltage which consists of voltage regulation circuit, control circuit and servo motors. When input voltage or loading changed, control circuit can sample and magnify, then drive the rotation of servo-motor and change the position of voltage regulator’s carbon bush. It finally maintains stable voltage through automatically adjusting the ratio of inductor.
      Automatic voltage stabilizer can maintain stable voltage for protecting different types of equipments and appliances.
      Precautions are as follow:
    1 、No strong vibration and corrosive liquid.
    2 、Keep clean inside
    3 、Operate the machine according to machine operation manual.
    4、Don’t watering AVR.
    5、Contact us if you have another difficult issues on our product.
    EPSI-5000 pure wave sine inverter 3

    EPSI-5000 pure wave sine inverter 4

    EPSI-5000 pure wave sine inverter 5



    Quick Details
    Place of Origin: Guangdong, China (Mainland)
    Brand Name: Powerhero
    Model Number: EPSI-5000
    Output Power: 3500W
    AC charging current selected 10A/15A.
    NO-loading current less than 1.2A.
    Size: 355*220*250mm
    Output Frequency: 50HZ/60HZ
    LED Display selectable


    Packaging & Delivery
    Packaging Details:
    Export special carton
    Delivery Detail:
    20days


    Features :
    With wide AVR range 140-275 Vac gives you stable voltage at mains mode
    Big charging current, 3 stage battery charger
    A true sine wave with very low harmonic distortion
    True C.R.G.O toroidal transformer ,lower static loss, more energy-saving
    32-bit high speed MCU control with accurate detection
    Smart digital display
    Integrated frequency automatic tracking technology, generator compatible


    Model EPSI-500 EPSI-800 EPSI-1000 EPSI-1500 EPSI-2000 EPSI-2500 EPSI-3000
    Rated Capacity 500VA 800VA 1000VA 1500VA 2000VA 2500VA 3000VA
    Rated Power 300W 500W 700W 1050W 1400W 1800W 2100W
    Transformer C.R.G.O
    Interface LED graphic
    Display Status working & loading & battery
    Working Mode PV(Photovoltaic priority) / ACAC priorityOptional
    Input Voltage 140~275 Vac
    Frequency 45~65 Hz
    Output Voltage 220Vac ±3% for inverter;190V-245V for avr
    Frequency 50/60 Hz ± 0.3Hz, subject to the main
    Wave Form Pure sinve wave
    Wave Distortion ≤ 3%
    Protection overload / high temperature / output high voltage / output low voltage / battery low voltage / short circuit / over-charge / over-discharge / reversed polarity(optional)
    Transfer Time ≤ 4ms
    Battery Voltage 12V DC 12V DC 12V DC 24V DC 24V DC 24V DC 48V DC
    Charge Voltage 13.8V±0.5V 13.8V±0.5V 13.8V±0.5V 27.6V±0.6V 27.6V±0.6V 27.6V±0.6V 55V±1V
    Low Battery Voltage Limit 10.9V ±0.3V 10.9V ±0.3V 10.9V ±0.3V 21.8V ±0.6V 21.8V ±0.6V 21.8V ±0.6V 42V ±1V
    Battery Low Voltage Protection Point 10.2V ±0.3V 10.2V ±0.3V 10.2V ±0.3V 20.5V ±0.6V 20.5V ±0.6V 20.5V ±0.6V 41V ±1V
    Charge Current Max. 10A/15A/20A optional
    Cooling System Yes
    Environmental Operating Temperature 0 - 40 ℃
    Relative Humidity 10%~90% RH, non-condensing
    Storage Temperature ﹣15 - 45 ℃
    Packing Machine Size(mm) 230x145x180 337x146x170 355x220x250
    Qty/Ctn 4 4 2 2 1 1 1
    Carton Size (mm) 785x305x240 415x410x255 395x272x305
    Carton G.W. (kg) 22 26 17.2 19.1 13 14.8 16.1
    We are offering 1 year warranty for all products and parts according. We also are offering technical training for you to make better use of our products.
