professional stabilizers & Inverters manufacturer and solution provider for 22 years
Packaging Details: |
Export special carton |
Delivery Detail: |
20days |
Model | EPSI-500 | EPSI-800 | EPSI-1000 | EPSI-1500 | EPSI-2000 | EPSI-2500 | EPSI-3000 | |
Rated Capacity | 500VA | 800VA | 1000VA | 1500VA | 2000VA | 2500VA | 3000VA | |
Rated Power | 300W | 500W | 700W | 1050W | 1400W | 1800W | 2100W | |
Transformer | C.R.G.O | |||||||
Interface | LED graphic | |||||||
Display Status | working & loading & battery | |||||||
Working Mode | PV(Photovoltaic priority) / AC(AC priority)Optional | |||||||
Input | Voltage | 140~275 Vac | ||||||
Frequency | 45~65 Hz | |||||||
Output | Voltage | 220Vac ±3% for inverter;190V-245V for avr | ||||||
Frequency | 50/60 Hz ± 0.3Hz, subject to the main | |||||||
Wave Form | Pure sinve wave | |||||||
Wave Distortion | ≤ 3% | |||||||
Protection | overload / high temperature / output high voltage / output low voltage / battery low voltage / short circuit / over-charge / over-discharge / reversed polarity(optional) | |||||||
Transfer Time | ≤ 4ms | |||||||
Battery Voltage | 12V DC | 12V DC | 12V DC | 24V DC | 24V DC | 24V DC | 48V DC | |
Charge Voltage | 13.8V±0.5V | 13.8V±0.5V | 13.8V±0.5V | 27.6V±0.6V | 27.6V±0.6V | 27.6V±0.6V | 55V±1V | |
Low Battery Voltage Limit | 10.9V ±0.3V | 10.9V ±0.3V | 10.9V ±0.3V | 21.8V ±0.6V | 21.8V ±0.6V | 21.8V ±0.6V | 42V ±1V | |
Battery Low Voltage Protection Point | 10.2V ±0.3V | 10.2V ±0.3V | 10.2V ±0.3V | 20.5V ±0.6V | 20.5V ±0.6V | 20.5V ±0.6V | 41V ±1V | |
Charge Current | Max. 10A/15A/20A optional | |||||||
Cooling System | Yes | |||||||
Environmental | Operating Temperature | 0 - 40 ℃ | ||||||
Relative Humidity | 10%~90% RH, non-condensing | |||||||
Storage Temperature | ﹣15 - 45 ℃ | |||||||
Packing | Machine Size(mm) | 230x145x180 | 337x146x170 | 355x220x250 | ||||
Qty/Ctn | 4 | 4 | 2 | 2 | 1 | 1 | 1 | |
Carton Size (mm) | 785x305x240 | 415x410x255 | 395x272x305 | |||||
Carton G.W. (kg) | 22 | 26 | 17.2 | 19.1 | 13 | 14.8 | 16.1 |
